Cable routing for the power button with LED
Read this section to learn about cable routing for the power button with LED.
Figure 27. Cable routing for the power button with LED
Table 24. Cable routing for the power button with LED
From To
1 Power button with LED cable
Power button with LED connector
Make sure to follow the “Cable routing guidelines” in “Internal cable routing” on page 19.
For the system-board connector locations, see “System board components” on page 18.
