Step 2. Remove the front bezel.
a.
Release the three plastic tabs on the front bezel.
b.
Rotate the front bezel to remove it from the chassis.
Figure 35. Removing the front bezel
Remove the CMOS battery (CR2032)
S002
CAUTION:
The power-control button on the device and the power switch on the power supply do not turn off the
electrical current supplied to the device. The device also might have more than one power cord. To
remove all electrical current from the device, ensure that all power cords are disconnected from the
power source.
Chapter 3. Server hardware setup 53
