Figure 33. Removing the serve cover
Step 3. (Optional) Remove the cage bar. Remove the optical drive cage first, see “Remove the optical
drive cage” on page 75; then, proceed to the following procedures.
a.
Push the latch on the cage bar until the cage bar is disengaged from the chassis.
b.
Rotate the cage bar and remove it from the chassis.
Figure 34. Removing the cage bar
Remove the front bezel
Follow this procedure to remove the front bezel.
Chapter 3. Server hardware setup 51
