Figure 32. Removing the server from the rails
After you finish
1. Place the server on its side with the cover up.
2. To install the server to the rails, see “Install the server to the rails” on page 95.
Remove the server cover
Follow this procedure to remove the server cover.
S002
CAUTION:
The power-control button on the device and the power switch on the power supply do not turn off the
electrical current supplied to the device. The device also might have more than one power cord. To
remove all electrical current from the device, ensure that all power cords are disconnected from the
power source.
S014
CAUTION:
Hazardous voltage, current, and energy levels might be present. Only a qualified service technician is
authorized to remove the covers where the label is attached.
Chapter 3. Server hardware setup 49
