34
V340-17IWL Hardware Maintenance Manual
Step3: Removethescrew
3
.
Step4: Carefullyremovetheopticaldrivebracketandbezelinthe 
 directionsshownbyarrows
4
and
5
.
3
4
5
Figure 2. Remove the optical drive bracket and bezel
Step Screw (quantity) Color Torque
3
M2×3mm,Phillipshead,nylok-coated(1) Black 1.85+/-0.15kgf/cm
