Lenovo V340 - 1050 Ssd Card

43
Lenovo V340-17IWL
1050 SSD card
Foraccess,removetheFRUinfollowingorder:
• “1010Opticaldrive”onpage33
• “1020Basecover”onpage35
• “1040Batterypack”onpage41
Attention:
• DonotdroptheSSDcardorapplyanyphysicalshocktoit. The SSD card is
sensitive to physical shock. Improper handling can cause damage and permanent
loss of data.
• Before removing the SSD card, suggest the customer to backup all the information
on it if possible.
• Never remove the SSD card while the system is operating or in suspend mode.
Step1: Removethescrew
1
.
1
Figure 10. Remove the screw
Step Screw (quantity) Color Torque
1
M2×6mm,Phillips-head,nylok-coated(1) Black 1.85+/-0.15kgf/cm
