Lenovo V340 - 1040 Battery Pack

41
Lenovo V340-17IWL
1040 Battery pack
DANGER
Only use the battery specied in the parts list for your computer. Any other battery
could ignite or explode.
Foraccess,removetheFRUinfollowingorder:
• “1010Opticaldrive”onpage33
• “1020Basecover”onpage35
Step1: Detachthebatterypackconnectorinthedirectionshownbyarrow
1
.
Step2: Removethescrews
2
.
2
2
2
2
2
1
Figure 8. Detach the battery pack connector and remove the screws
Step Screw (quantity) Color Torque
2
M2×6mm,Phillips-head,nylok-coated(5) Black 1.85+/-0.15kgf/cm
