Lenovo V340 - 1010 Optical Drive

33
Lenovo V340-17IWL
1010 Optical drive
Step1: Removethescrew
1
.
Step2: Pulltheopticaldriveoutinthedirectionshownbyarrow
2
.
1
2
Figure 1. Remove the optical drive
Step Screw (quantity) Color Torque
1
M2.5×7mm,Phillipshead,nylok-coated(1) Black/
Silver
3.0+/-0.3kgf/cm
