53
Lenovo V340-17IWL
Step2: Removethescrews
2
.
Step3: Removethesystemboardinthedirectionshownbyarrow
3
.
2
2
3
Figure 22. Remove the screws and system board
Step Screw (quantity) Color Torque
2
M2×3mm,Phillips-head,nylok-coated(2) Black 1.85+/-0.15kgf/cm
