Mechanical installation
Motor mounting
Scope of supply
4
86
EDK82MV752 DE/EN/FR 7.2
4.3 Motor mounting
4.3.1 Scope of supply
8200mot449
01
3
4
5
2
M5 x 65
8200 motec (electronic module and carrier housing)
Adapter plate
Flat gaskets for adapter plate
Support for function modules and electrical connection for fan module
Fan module E82ZMV
4 screws M5 × 65 mm for mounting the carrier housing on the fan module
