Lenze · Decentralised frequency inverter 8400 motec (AS-Interface option) · EDS84DMOTASI EN 4.0 - 09/2013 62
Parameter reference
Parameters relevant for AS-i communication
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13204
C13205
C13206
Parameter | Name:
C13204 | Override Slave Addresses
Data type: UNSIGNED_8
Index: 11371 = 0x2C6B
Selection list (Lenze setting printed in bold)
0Off / ready
1On / start
2In progress
3 Action failed
4 Action cancelled
5No access
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13205 | Override of slave addresses during initialisation
Data type: UNSIGNED_8
Index: 11370 = 0x2C6A
Selection list (Lenze setting printed in bold)
0 Disable
1Enable
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13206 | Slave profiles
Data type: UNSIGNED_16
Index: 11369 = 0x2C69
Value is bit-coded:
Bit 0 ID_Code_2_Bit0
Bit 1 ID_Code_2_Bit1
Bit 2 ID_Code_2_Bit2
Bit 3 ID_Code_2_Bit3
Bit 4 ID_Code_1_Bit0
Bit 5 ID_Code_1_Bit1
Bit 6 ID_Code_1_Bit2
Bit 7 ID_Code_1_Bit3
Bit 8 ID_Code_Bit0
Bit 9 ID_Code_Bit1
Bit 10 ID_Code_Bit2
Bit 11 ID_Code_Bit3
Bit 12 IO_Configuration_Bit0
Bit 13 IO_Configuration_Bit1
Bit 14 IO_Configuration_Bit2
Bit 15 IO_Configuration_Bit3
Subcodes Info
C13206/1 Slave 1 Profile
C13206/2 Slave 2 Profile
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
