Lenze 8400 motec - Page 63

Parameter reference
Parameters relevant for AS-i communication
63
Lenze · Decentralised frequency inverter 8400 motec (AS-Interface option) · EDS84DMOTASI EN 4.0 - 09/2013
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13207
C13208
C13210
Parameter | Name:
C13207 | Response in case of communication fault
Data type: UNSIGNED_8
Index: 11368 = 0x2C68
The response set here is triggered if the AS-i node does not receive a message from the master within the
monitoring time (C13208
) or detects that it has exited the DATA_EXCHANGE status.
A change in the monitoring response becomes immediately effective.
Selection list (Lenze setting printed in bold)
0 No response
1Fault
4 Warning Locked
Subcodes Lenze setting Info
C13207/1 1 Slave 1 communication timeout
C13207/2 1 Slave 1 communication timeout - CTT2 extended cyclic
C13207/3 1 Slave 2 communication timeout
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13208 | AS-i monitoring times
Data type: UNSIGNED_16
Index: 11367 = 0x2C67
If the DATA_EXCHANGE status is exited, the response parameterised in C13207/1...3 is carried out when the time
set here for the data exchange has elapsed.
• The value "65535" is used to deactivate the monitoring.
• A change in the monitoring is immediately effective.
Setting range (min. value | unit | max. value)
0 ms 65535
Subcodes Lenze setting Info
C13208/1 3000 ms Slave 1 monitoring time
C13208/2 3000 ms Slave 1 monitoring time - CTT2 extended cyclic
C13208/3 3000 ms Slave 2 monitoring time
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13210 | AS-i Bus transaction counter
Data type: UNSIGNED_16
Index: 11365 = 0x2C65
Display of AS-i transactions
Display range (min. value | unit | max. value)
0 65535
Subcodes Info
C13210/1 Slave 1 - Data cycles
C13210/2 Slave 1 - Parameter cycles
C13210/3 Slave 1 - CTT2 extended cyclic cycles
C13210/4 Slave 1 - CTT2 acyclic access cycles
C13210/5 Slave 2 - Data cycles
C13210/6 Slave 2 - Parameter cycles
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
