13.2 Parameters of the communication module for slot MXI1
This chapter lists the parameters of the E94AYCEO communication module (EtherNet/IP) for slot
MXI2 of the Servo Drive 9400 in numerically ascending order.
C13000
C13001
C13002
Parameter | Name:
C13000 | IP address
Data type: UNSIGNED_8
Index: 11575 = 0x2D37
Setting of the IP address
Setting the IP configuration of the Servo Drive 9400
( 37)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C13000/1 192 IP address (most significant byte)
C13000/2 168 IP address
C13000/3 124 IP address
C13000/4 16 IP address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13001 | Subnetwork Mask
Data type: UNSIGNED_8
Index: 11574 = 0x2D36
Setting of the subnet mask
Setting the IP configuration of the Servo Drive 9400
( 37)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C13001/1 255 Subnet mask (most significant byte)
C13001/2 255 Subnet mask
C13001/3 255 Subnet mask
C13001/4 0 Subnet mask (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13002 | Gateway address
Data type: UNSIGNED_8
Index: 11573 = 0x2D35
Setting of the gateway address
Setting the IP configuration of the Servo Drive 9400
( 37)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C13002/1 0 Gateway address (most significant byte)
C13002/2 0 Gateway address
C13002/3 0 Gateway address
C13002/4 0 Gateway address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
