14 Implemented CIP™ objects
14.1 General CIP objects
121
Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.1 General CIP objects
14.1.1 Identity Object (1 / 0x01)
The "Identity Object" provides the identification and general information about the device.
Class attributes
Instance attributes
1) The status is set if the pending, status determining device error displays the fault, trouble, quick stop by trouble, warning
locked, or warning response.
2) The status is set if the pending, status determining device error displays the system fault response.
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 1 (0x0001)
2 Get Max. Instance UINT 1 (0x0001)
3 Get Number of Instances UINT 1 (0x0001)
6 Get Max. ID Number Class
Attributes
UINT 7 (0x0007)
7 Get Max. ID Number Instance
Attributes
UINT 10 (0x000A)
Attribute
ID
Service Name Data type Value
1 Get Vendor ID UINT 587 (0x024B)
2 Get Device Type UINT 43 (0x002B)
3 Get Product Code UINT 9400 (0x24B8)
4 Get Revision: STRUCT of: Firmware revision of the device
Major Revision USINT
Minor Revision USINT
5 Get Status WORD Current device status (status bits)
• Instance attribute "Status" (attribute 5)
( 122)
• EtherNet/IP state diagram
( 50)
6 Get Serial Number UDINT Serial number of the device
7 Get Product Name SHORT_STRING E94AYCEO
8 Get State USINT Current device state:
•0: Nonexistent
•1: Device self-testing
•2: Standby
•3: Operational
• 4: Major Recoverable Fault
1)
• 5: Major Unrecoverable Fault
2)
• 6 ... 254: Reserved
• 255: Standard for "Get_Attributes_All"
service
(See also C13861
/ C14861, LED status
displays ( 76))
