14 Implemented CIP™ objects
14.3 Lenze objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.3.3 Lenze Class (104 / 0x68)
The "Lenze Class (104 / 0x68)" provides the image of the scanner output data.
The output data of the scanner are transmitted via the assembly object instance 110 (0xE5, Custom
Output).
Class attributes
Instance attributes
Supported service codes
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 2 (0x0002)
2 Get Max. Instance UINT 1 (0x0001)
Attribute
ID
Service Name Data type Value
1 Get No. of supported Attributes USINT 3 (0x0003)
2 Get Attribute List USINT 1 (0x0001) ... 3 (0x0003)
3 Get I/O image of consumed data USINT Image of the scanner output data
Service code
[hex]
Name Description
0x01 Get_Attributes_All Outputs a list of the attributes and the attribute's values for
a certain object.
0x0E Get_Attribute_Single Outputs the value of a certain attribute.
