Fusing data
Branch Circuit Protecon (BCP)
Short Circuit Current Rangs (SCCR) with Standard Fuses and Circuit Breaker
(Tested per UL61800-5-1, reference UL le E132659)
These devices are suitable for motor group installaon when used with Standard Fuses and Circuit Breaker.
For single motor installaon, if the fuse value indicated is higher than 400 % of the motor current (FLA), the
fuse value has to be calculated. If the value of the fuse is below two standard rangs, the nearest standard
rangs less than the calculated value shall apply.
Inverters Standard Fuses (UL248) Circuit Breaker (UL489)
Mains
Rated
power
SCCR Max. rated current Class SCCR Max. rated current Min. cabinet dimensions
kW HP kA A kA A m³ ³
230 V, 1/3-ph 0.37 0.5 65 35 CC, CF, J, T 65 25 0.042 1.48
230 V, 1/3-ph 0.55 0.75 65 35 CC, CF, J, T 65 25 0.042 1.48
230 V, 1/3-ph 0.75 1 65 35 CC, CF, J, T 65 25 0.042 1.48
230 V, 1/3-ph 1.5 2 65 35 CC, CF, J, T 65 25 0.042 1.48
230 V, 3-ph 2.2 3 65 35 CC, CF, J, T 65 25 0.042 1.48
230 V, 3-ph 4 5 65 60 CC, CF, J, T 65 60 0.042 1.48
230 V, 3-ph 5.5 7.5 65 60 CC, CF, J, T 65 60 0.042 1.48
480 V, 3-ph 0.55 0.75 65 35 CC, CF, J, T 65 25 0.042 1.48
480 V, 3-ph 0.75 1 65 35 CC, CF, J, T 65 25 0.042 1.48
480 V, 3-ph 2.2 3 65 35 CC, CF, J, T 65 25 0.042 1.48
480 V, 3-ph 4 5 65 35 CC, CF, J, T 65 25 0.042 1.48
480 V, 3-ph 7.5 10 65 60 CC, CF, J, T 65 60 0.042 1.48
480 V, 3-ph 11 15 65 60 CC, CF, J, T 65 60 0.042 1.48
480 V, 3-ph 15 20 65 60 CC, CF, J, T 65 60 0.042 1.48
480 V, 3-ph 22 30 65 70 CC, CF, J, T 65 70 0.17 6
480 V, 3-ph 30 40 22 125 CC, CF, J, T 35 125 0.57 20
480 V, 3-ph 45 60 22 125 CC, CF, J, T 35 125 0.57 20
480 V, 3-ph 55 75 22 200 CC, CF, J, T 35 200 0.57 20
480 V, 3-ph 75 100 22 200 CC, CF, J, T 35 200 0.57 20
480 V, 3-ph 90 125 22 300 CC, CF, J, T 10 300 0.57 20
480 V, 3-ph 110 150 22 300 CC, CF, J, T 10 300 0.57 20
Electrical ins
tallaon
Connecon according to UL
Fusing data
134

Lenze i950 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Altitude	Up to 1000 m without derating
Control Modes	V/f control, vector control, servo control
Communication Interfaces	EtherCAT, PROFINET, CANopen, Modbus TCP
Ambient Temperature	-10°C to 40°C
Safety	STO (Safe Torque Off), SS1 (Safe Stop 1), SLS (Safely Limited Speed)
Cooling Method	Air cooling
Frequency Range	0 to 599 Hz
Relative Humidity	5% to 95% (non-condensing)
Input Voltage	200 V to 480 V
Output Voltage	0 V to 480 V
Storage Temperature	-25 to +70 °C (-13 to 158 °F)
