Lenze i950 Series User Manual

Terminal data
Rated power P
rated
kW 0.55 ... 4 7.5 ... 15 22 30 ... 45 55 ... 75 90 ... 110
Connecon descripon Mains c
onnecon
Connecon X100
Connecon type Pluggable Not pluggable
Max. cable cr
oss-secon mm² 2.5 16 35 50 95 150
Max. cable cr
oss-secon AWG 12 6 2 1/0 4/0 -
Stripping length mm 8 14 18 19 22 28
Stripping length in 0.3 0.55 0.7 0.75 0.87 1.1
Tightening torque Nm 0.5 1.8 3.8 4 10 18
Tightening torque lb-in 4.4 16 34 35 89 160
Required tool 0.5 x 3.0 0.8 x 4.0 0.8 x 5.5 Hexagon
sock
et 5.0
Hexagon
socket 6.0
Hexagon
socket 8.0
Rated power P
rated
kW 0.55 ... 4 7.5 ... 15 22 ... 75 90 ... 110
Connecon descripon PE c
onnecon
Connecon PE
Max. cable cr
oss-secon mm² 6 16 25 150
Max. cable cr
oss-secon AWG 10 6 2 -
Stripping length mm 10 11 16 -
Stripping length in 0.4 0.4 0.6 -
Tightening torque Nm 2 3.4 4 10
Tightening torque lb-in 18 30 35 89
Required tool T20 PZ2 Wrench size 13
Rated power P
rated
kW 0.55 ... 4 7.5 ... 15 22 30 ... 45 55 ... 75 90 ... 110
Connecon descripon Motor c
onnecon
Connecon X105
Connecon type Pluggable Not pluggable
Max. cable cr
oss-secon mm² 2.5 16 35 50 95 150
Max. cable cr
oss-secon AWG 12 6 2 1/0 4/0 -
Stripping length mm 8 14 18 19 22 28
Stripping length in 0.3 0.55 0.7 0.75 0.87 1.1
Tightening torque Nm 0.5 1.8 3.8 4 10 18
Tightening torque lb-in 4.4 16 34 35 89 160
Required tool 0.5 x 3.0 0.8 x 4.0 0.8 x 5.5 Hexagon
sock
et 5.0
Hexagon
socket 6.0
Hexagon
socket 8.0
The terminal data for the terminal X1 can be found under:4Basic Sa
fety - STO ^ 167
The terminal data for the terminals X82 and X83 can be found under: 4T
erminal data ^ 172
Electrical ins
tallaon
Mains connecon
3-phase mains connecon 480 V
146

Lenze i950 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Altitude	Up to 1000 m without derating
Control Modes	V/f control, vector control, servo control
Communication Interfaces	EtherCAT, PROFINET, CANopen, Modbus TCP
Ambient Temperature	-10°C to 40°C
Safety	STO (Safe Torque Off), SS1 (Safe Stop 1), SLS (Safely Limited Speed)
Cooling Method	Air cooling
Frequency Range	0 to 599 Hz
Relative Humidity	5% to 95% (non-condensing)
Input Voltage	200 V to 480 V
Output Voltage	0 V to 480 V
Storage Temperature	-25 to +70 °C (-13 to 158 °F)
