Electrical installation
Control terminals
6
l
35
LDEDS−CCU210B EN 4.0
X45 − digital inputs DIN5/DOUT2 − DIN6
Pin Signal Description Data
Connector: socket, 4−pole, M12
1 +24V DC Supply HIGH +16 .... +26.5 V DC
2
1)
DIN5 Digital input 5 LOW 0 ... +4 V
DOUT2
Digital output 2 4 mA Current per input for 24 V DC
3
GND Reference potential
max.
200 mA
Permissible current loading per
output
If inductive loads are being
switched, a spark suppressor
must be used at the output!
4 DIN6 Digital input 6
1)
DIN/DOUT cannot be used at the same time!
