Troubleshooting and fault elimination
Status display
9
l
79
LDEDS−CCU210B EN 4.0
Standard displays
Standard displays during operation (C0500 = 0)
Pos. Display Description
1
8.
8. 8. 8. Power−up display for 0.5 s
2. 3 4 Software version for 0.5 s
f 8 8 8 Error message (blinking)
h 8 8 8 Warning signal (blinking)
I n h Controller inhibit active (C0040)
o f f ON/OFF switch in OFFposition
P A R Parameters are saved in the EEPROM
P d A Manual PDA operation via IrDA active
I R C Manual infrared operation active
1 V1 forwards active
2 V2 forwards active
3 V3 forwards active
4 V4 forwards active
5 V5 forwards active
6 V6 forwards active
7 V7 forwards active
8 V8 forwards active
1 − V1 backwards active
2 − V2 backwards active
3 − V3 backwards active
4 − V4 backwards active
5 − V5 backwards active
6 − V6 backwards active
7 − V7 backwards active
8 − V8 backwards active
R 8. 8 8 Vv (variable frequency selection HWC Code Range) forward active
d Starting delay function active
P o. 8 8 IrDA positioning active
P o. −| |− IrDA positioning − position reached
1
1 ’ SensoPart: parameter set 1 active
2 ’ ’ SensoPart: parameter set 2 active
B o "Open brake" active
s 1. Stop 1 active
s 2. Stop 2 active
s 3. Stop 3 active
s 4. Stop 4 active
s d. SensoPart: stop distance active
s e. SensoPart: stop "Emergency distance" active
l b. SensoPart: creeping speed active
l d. SensoPart: approach speed active
l 1. Frequency limitation 1 active
l 2. Frequency limitation 2 active
l 3. Frequency limitation 3 active
l 4. Frequency limitation 4 active
8 8 Current drive frequency [Hz]
