Lenze · E84AYCPM communication module (PROFIBUS®) · Communication Manual · DMS 5.0 EN · 11/2012 · TD17 112
Index
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
E
Electrical installation 25
E-mail to Lenze 114
Error: Lenze settings loaded (error message) 93
Error codes (DP-V0) 58
Error codes (DP-V1) 74
Error messages 91
Causes and remedies 92
Short overview 91
Error number
0x01bc3100
92
0x01bc5531 92
0x01bc5532 92
0x01bc5533 92
0x01bc6010 92
0x01bc6011 93
0x01bc6100 93
0x01bc6101 93
0x01bc6110 93
0x01bc641f 93
0x01bc6420 93
0x01bc8130 94
0x01bc8131 94
0x01bc8132 94
Establishing communication 34
F
Features 14
Feedback to Lenze 114
Fieldbus status displays 86
Firmware compilation date (C13901) 101
Firmware product type (C13900) 101
Firmware version (C13902) 102
G
General data 15
General safety and application instructions 11
Going online with »Engineer« via TCI 35
I
Identification 13
Initial switch-on 34
Installation 21
Interface 15
Interfaces 14
Internal error (error message) 93
Invalid parameter record (error message) 93
L
LED status displays 84
M
Mechanical installation 22
Memory
No access (error message)
92
Read error (error message) 92
Write error (error message) 92
Module status displays 85
Monitoring 81
Permanent interruption of PROFIBUS communication 81
Settings and displays in the »Engineer« 83
Short-time interruption of PROFIBUS communication 82
Monitoring time
Data exchange (C13881)
99
Watchdog (C13882) 100
Mounting for 0.25 kW and 0.37 kW standard devices 22
Mounting for standard devices of 0.55 kW and more 23
N
Nameplate 13
Network topology 15, 25
Notes used 10
Number of stations 15, 26
O
Operating conditions 15
P
Parameter addressing 51
Parameter data transfer 51
Parameter reference 95
Parameters of the communication module 95
PDO mapping 45
PNO identification number 15
Process data transfer 45
Processing time 19
Product description 13
Profibus: Data_Exchange state exited (error message) 94
PROFIBUS connection 29
PROFIBUS error messages
Causes and remedies
92
Short overview 91
Profibus watchdog
DP-V1 MSC2 monitoring time exceeded (error message)
94
Monitoring time elapsed (error message) 94
PROFIdrive 61
PROFIdrive objects (DP-V1) 105
PROFIdrive parameter data channel (DP-V1) 61
Protection against uncontrolled restart 34
Protection of persons 12
Protective insulation 16
Protocol data 19
