Lenze SMVector Reference Guide

CMVETH01B 70
Reference
9.2.11 Ethernet Link Object - Class 0xF6 (246 dec)
ETHERNET LINK CLASS ATTRIBUTES
Attribute ID Access Rule Name Data Type Value
INSTANCE 0
1 GET REVISION UINT 2
ETHERNET LINK INSTANCE ATTRIBUTES
Attribute ID Access Rule Name Data Type Value
INSTANCE 1
1 GET INTERFACE SPEED UDINT speed in Mbps
2 GET INTERFACE FLAGS DWORD
3 GET PHYSICAL ADDRESS ARRAY of 6 USINT MAC layer address
6 SET
INTERFACE CONTROL STRUCT of:
CONTROL BITS WORD
FORCED INTERFACE SPEED UINT speed in Mbps
ETHERNET LINK CLASS SERVICES
SERVICE CODE IMPLEMENTED FOR SERVICE NAME
CLASS INSTANCE
0x0E YES YES Get_Attribute_Single
0x10 NO YES Set_Attribute_Single

Lenze SMVector Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Communication Options	CANopen, Profibus DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Control Method	Sensorless Vector
Ambient Temperature	-10°C to +40°C
