Lenze SMVector Reference Guide

57 CMVETH01B
Reference
9 Reference
9.1 Parameter Reference
Table 25 lists the EtherNet/IP related parameters and settings for the SMVector Drive. The table includes
parameter number, name, access rights, default value, settings and comments.
Table 25: SMV EtherNet/IP Communication Parameters
No Name Access Default Possible Settings Comments
EtherNet/IP Module Specific Parameters
400 Network Protocol R/W 5 0 – Not Active
5 – Ethernet IP
401 Module Revision RO Display reads 06.x.x where:
06 = Ethernet IP Module
x.x = Module Revision
402 Module Status RO 0 0 … 7 0 - Not Initialized
1 – Initialization: Module to EPM
2 – Initialization: EPM to Module
3 – Online
4 – Failed Initialization Error
5 – Time-out Error
6 – Initialization Failed (Module type mismatch P401)
7 – Initialization Error (Protocol selection mismatch P400)
403 Module Reset R/W 0 0 – No Action
1 – Reset Module Parameters values to default
Returns module parameters 401…499 to the default values shown
in the manual
404 Module Time-out action R/W 0 0 – No Fault
1 – STOP (see P111)
2 – Quick Stop
3 – Fault (F_ntF)
Action to be taken in the event of a Module/Drive Time-out.
Time is fixed at 200ms
Selection 1 (STOP) is by the method selected in P111
405 Current Network Fault RO 0 – No Fault
1 – F.nF1
2 – F.nF2
3 – F.nF3
4 – F.nF4
5 – F.nF5
6 – F.nF6
7 – F.nF7
0 – No Fault
1 – F.nF1 – NetIdle Mode
2 – F.nF2 – Loss of Ethernet I/O connection
3 – F.nF3 – Network Fault triggered via Control Supervisor Object
0x29-1-17
4 – F.nF4 – Explicit Message Timeout
5 – F.nF5 – Overall Network Timeout
6 – F.nF6 – Overall Explicit Timeout
7 – F.nF7 – Overall I/O Message Timeout
406 Proprietary RO Manufacturer specific
EtherNet/IP Configuration Parameters
408 Initialize Ethernet/IP settings R/W 0 0 – No action
1 – reset communication
Re-initialize Ethernet/IP
IP Address R/W
410 Digit 1 192 Highest quarter
411 Digit 2 168
412 Digit 3 124
413 Digit 4 16 Lowest quarter
Network Mask R/W
414 Digit 1 255 Highest quarter
415 Digit 2 255
416 Digit 3 255
417 Digit 4 0 Lowest quarter
Gateway Address R/W
418 Digit 1 192 Highest quarter
419 Digit 2 168
420 Digit 3 124
421 Digit 4 1 Lowest quarter
Multicast Address R/W
422 Digit 1 239 Highest quarter
423 Digit 2 64
424 Digit 3 2
425 Digit 4 224 Lowest quarter
