Lenze Starttec E71MM402 - Preparation

Wall mounting
Preparation
4
EDK71MMXXX-020 DE/EN/FR 1.0
19
L
Abb. 1-12
c
a
d
b
5.3 mm
3.4 Nm
30 lb-in
1a
2
4
3
e
4 × 6 ×
M20 M16
1a
1a
start022
21
Distance and wall mounting plate Drilling pattern Distance
a [mm] b [mm] c [mm] d [mm] e [mm]
85 110 71 96 12
