Commissioning
Before switching on
7
EDK71MMXXX-020 DE/EN/FR 1.0
29
L
Stop!
Short circuits or earth faults in the wiring destroy the starttec. Check the wiring for short
circuit and earth fault.
Tip!
l Do not change the switch-on sequence.
l In the event of an error during commissioning please see the chapter ”Fault
detection and elimination”.
Check the following to avoid damage to persons or material...
...before the mains voltage is connected:
l Completeness, short circuit and earth fault
l ”Emergency-off” function of system
l The startec control mode (C0014) must be adapted to the wiring. Otherwise, the starttec can
be damaged:
– Two motors, one direction of rotation: C0014 = 0 (Lenze setting)
– One motor, change of direction of rotation: C0014 = 1!
... the most important drive parameter settings before the starttec can be enabled:
l Are the drive parameters relevant for your application set correctly?
– E. g. co nfiguration of digital inputs and outputs
