7
Commissioniong
Multi-motor operation - without keypad
EDK71MMXXX-020 DE/EN/FR 1.0
L
30
Danger!
Extremely dangerous voltage at power connections.
l The device must be disconnected from the mains volta ge when it is open.
l Even if the starttec is inhibited (X3/28 = LOW), the connectio ns 1V, 2V, B1 and B2
carry dangerous voltage!
Stop!
l Without keypad, the type 2 starttec can only be set up for ”multi-motor operation”!
l Never try to set up the control mode ”change of directio n of rotation” without a
keypad. The starttec type 2 can be damaged!
Tip!
Potentiometer and switch settings always apply to both motors.
We therefore recommend to use the keypad for ”multi-motor operation” because it is then
possible to individually set every motor.
With Lenze setting (C0006 = -0-), acceleration time (C0012), start voltage (C0016) and rated current
(C0120) can only be set via potentiometer or switch.
Step switch [S] Motor power at mains voltage Note
Position Rated
current
230 VAC 400 VAC 500 VAC
0 – – – – No I
2
t monitoring
1 1.0 A – 0.25 kW 0.37 kW
2 1.4 A – 0.37 kW 0.55 kW
3 1.8 A 0.25 kW 0.55 kW 0.75 kW
4 2.4 A 0.37 kW 0.75 kW 1.1 kW
5 3.0 A 0.55 kW 1.1 kW 1.5 kW
6 4.0 A 0.75 kW 1.5 kW 2.2 kW
7 5.5 A 1.1 k W 2.2 kW 3.0 kW
8 7.0 A 1.5 k W 3.0 kW 4.0 kW
9 9.5 A 2.2 k W 4.0 kW 5.5 kW
