Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
Vector speed control
loop gain
30.0 0.0 100 Optimizes dynamic performance in vector
mode
Vector speed stability 30.0 0.0 100 Optimizes steady-state speed stability in
vector mode
7
I
max
gain 0.25 0.00 16.0 For most applications, there is no need to
change the Lenze settings
(1)
Integral action time 65 12 {ms} 9990
Motor stator resistance 0.00 0.00 {Ω} 64.0 Will be automatically programmed by c48
(1)
Motor rated power 0.00 {kW} 99.9 • Set to motor nameplate kW
• Lenze setting = Tmd rated kW
7
Motor rated speed 1390 300 {RPM} 65000 Set to motor nameplate speed
Motor rated current 0.0 0.0 {A} 480 Set to motor nameplate current
Motor rated frequency 50 10 {Hz} 999 Set to motor nameplate frequency
Motor rated voltage 0 0 {V} 600 Set to motor nameplate voltage
1
Motor cosine phi 0.80 0.40 1.00 Set to motor power factor
Note
If motor power factor is not known, use the following formulas:
cos phi = motor Watts / (motor efciency X C90 X C88 X 1.732)
cos phi = cos [ sin-1 (magnetizing current / motor current) ]
Motor stator inductance 0.0 0.0 {mH} 2000 Will be automatically programmed by c48
(1)
Drive identification • Indicates controller rating, format: xyz,
xy.z, x.yz, or x.y.z
• x. or x = voltage (2. = 200/240V, 1~;
2 = 200/240V, 3~; 4 = 400/480V, 3~)
• yz or y.z = kW rating
Examples:
2.0.3 = 200/240 V, 1~, 0.37 kW
47.5 = 400/480 V, 3~, 7.5 kW
User password 0 0 999
Changing from “0” (no password), value will
start at 763
When set to a value other than 0, must enter
password at C00 to access parameters
Software version Display, format: x.yz
