Device parameters and interfaces
52 BPS 34 Leuze electronic
8.1.7.1 Module 1: Position value
Description:
With this module, the current position value is output.
Note!
The position value is the position value calculated from the tape value and the settings for
resolution, preset and offset.
Parameters
Hex coding of module 1 "Position value"
The value listed in the table shows the hex coding of the default settings.
Input data
Note!
A negative number is represented in the input data by a 1 in the most significant bit.
Output data
None
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Sign
Output mode for
sign.
0
unsign
8
0: Two's complement
1: Sign + magnitude
0 ––
Parameter length: 1 byte
a
Internal address of module 1 Sign
13 00
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Position
value
Output of the current position 0
sign
32
-10,000,000 … -10,000,000
(for a resolution in mm)
0 Scaled –
Input data length: 4 byte
b
