Leuze electronic BPS 34 - Page 54

Device parameters and interfaces
Leuze electronic BPS 34 53
TNT 35/7-24V
8.1.7.2 Module 2: Resolution
Description
With this module, the resolution for the position value of module 1 is defined. The BPS 34
also performs a rounding correction (The position value is divided by the defined value
range).
Note!
The resolution only determines the mathematical decimal value and has no effect on the
measurement accuracy.
Parameters
Hex coding of module 2 "Resolution"
The value listed in the table shows the hex coding of the default settings.
Input data
None
Output data
None
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Resolution
in [mm]
The parameter specifies the res-
olution for the position value. The
resolution has no effect on -
Static preset
- Dynamic preset
- Offset
0
unsign
8
1: 0.01
2: 0.1
3: 1
4: 10
5: 100
6: 1,000
3 mm –
Parameter length: 1 byte
a
Internal address of module 2 Resolution
0A 03
