Leuze electronic BPS 34 - Page 74

Device parameters and interfaces
Leuze electronic BPS 34 73
TNT 35/7-24V
8.1.7.15 Module 14: Static position limit value 1
Description
The limit value function compares the output position value with a position stored during
configuration. If the value is above or below the limit value, the limit value status 1
(module 12) is set and, if configured, the switching output (module 8) is appropriately set.
Parameters
Hex coding of module 14 "Static position limit value 1"
The value listed in the table shows the hex coding of the default settings.
Input data
None
Output data
None
Note!
With this module, the settings for the Preset (module 3), Offset (module 5) and Scaling
(module 6) modules must be taken into account.
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Limit value
mode 1
Parameter activates the limit
value check.
0
unsign
8
0: Off
1: On
0 –7g
Switching
type 1
Condition for the signal change
of the switching output/status bit.
1
unsign
8
0: Value greater than limit
1: Value less than limit
0 –8d
Hysteresis
1 in [mm]
Relative offset of the switching
point
2
unsign
16
0 … 65,535 0 mm –
Limit value
1 in [mm]
Limit value is compared to the
current position value.
4 sign32 -10,000,000 … 10,000,000 0 mm 12e
Parameter length: 8 byte
a
b
c
d
Internal address of module 14 Limit value mode 1 address 0 Switching type 1 address 1 Hysteresis 1 address 2 Limit value 1 address 4
0D 00 00 00 00 00 00 00 00
