Device parameters and interfaces
72 BPS 34 Leuze electronic
Input data
Output data
Note!
With "MinMax reset", the input data are reset to 155812h.
With this module, the settings for the Preset (module 3), Offset (module 5) and Scaling
(module 6) modules must be taken into account.
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Min.
position
Minimum position for detected
period.
0 sign32 -10,000,000 … 10,000,000
0
Reset:
2.147.4
83.647
Scaled –
Max.
position
Maximum position for detected
period.
4 sign32 -10,000,000 … 10,000,000
0
Reset:
-2.147.4
83.647
Scaled –
Input data length: 8 byte
c
d
Output
data
Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
MinMax
reset
Signal for resetting extreme
values
0.0 Bit 0 -> 1: Reset 0 –7
Output data length: 8 byte
