Device parameters and interfaces
Leuze electronic BPS 34 83
TNT 35/7-24V
Input data
Note!
These input data signal the state of the BPS 34:
•Init: Base setting during initial startup of the BPS 34
• Idle: The BPS 34 is in idle state (scanning beam is off, but motor is running)
• Measure: The BPS 34 is in measurement state (data are output in module 1)
• Standby: The BPS 34 is in waiting state (laser off and motor off).
Output data
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
State
Signals the current state of the
internal speed measurement of
the BPS 34.
0
unsign
8
0: Init
1: Idle
2: Measure
4: Standby
0 ––
Input data length: 1 byte
Output
data
Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Start
event
Event starts speed measure-
ment.
0.0 Bit 0 -> 1: Start 0 ––
Stop event
Event stops speed measure-
ment.
0.1 Bit 0 -> 1: Stop 0 ––
Min./max.
speed
mode
Defines whether the current
speed is included in the min./
max. recording.
0.2 Bit
0: Do not record min./max.
1: Record min./max.
0 –24
Min./max.
speed
reset
Reset the min./max. speed val-
ues.
0.3 Bit 0 -> 1: Reset 0 –24
Output data length: 1 byte
