Device parameters and interfaces
84 BPS 34 Leuze electronic
8.1.7.24 Module 23: Speed measurement status
Description
This module supplies various status information regarding the speed measurement of the
BPS 34 to the PROFIBUS master.
Parameters
None
Input data
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Speed
measure-
ment error
Signals that no valid speed
could be ascertained.
0.0 Bit
0: OK
1: Error
0 –21
Speed limit
value
status 1
Signals that the speed limit
value 1 has been exceeded.
0.1 Bit
0: No limit value violation
1: Value greater than limit
0 – 25a
Speed limit
value
status 2
Signals that the speed limit
value 2 has been exceeded.
0.2 Bit
0: No limit value violation
1: Value greater than limit
0 – 25a
Speed limit
value
status 3
Signals that the speed limit
value 3 has been exceeded.
0.3 Bit
0: No limit value violation
1: Value greater than limit
0 – 25a
Speed limit
value
status 4
Signals that the speed limit
value 4 has been exceeded.
0.4 Bit
0: No limit value violation
1: Value greater than limit
0 – 25a
Dyn. speed
limit value
status
Signals that the dynamic speed
limit value has been exceeded.
0.5 Bit
0: No limit value violation
1: Value greater than limit
0 – 26b
Movement
status
Signals whether a movement is
currently being detected.
0.6 Bit
0: No movement
1: Movement
0 ––
Direction
of move-
ment
If bit 6 is set, the direction of
movement can be read here.
0.7 Bit
0: Direction - tape start
1: Direction - tape end
0 ––
Speed limit
value
status 1
Signals whether the current
speed is compared with this
limit value.
1.1 Bit
0: Comparison not active
1: Comparison active
0 – 25a
Speed limit
value
status 2
Signals whether the current
speed is compared with this
limit value.
1.2 Bit
0: Comparison not active
1: Comparison active
0 – 25a
Speed limit
value
status 3
Signals whether the current
speed is compared with this
limit value.
1.3 Bit
0: Comparison not active
1: Comparison active
0 – 25a
