The speed limit value function compares the current speed with a stored speed within the
defined range. If the value is above or below the limit value, the dynamic limit value status
in module 23 is set and, if configured, the switching output is appropriately set. Limit value,
hysteresis, range start and range end are transferred with the output data of this module by
the PROFIBUS master. The transferred values are activated by bit 0.0, i.e. if this bit is set,
the BPS 34 compares the current speed with the new limit value conditions.
Parameters
None
Input data
None
Output data
Output
data
Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Limit value
control
Controls internal processing of
the transferred dynamic limit
value parameters.
0.0 Bit
0: Do not process
1: Parameter now valid /
process
0 –
8d
22
23f
23 m
Switching
type
Condition for the signal change
of the switching output and the
status bit for dynamic speed limit
value.
0.1 Bit
0: Value greater than limit
1: Value less than limit
0 –
Direction
selection
Selection of direction-depen-
dent or direction-independent
limit value check for dynamic
speed limit value.
0.2 Bits
0: Check in both direc-
tions
1: Only check in
one direction
0 –
Dyn. speed
limit value
in [mm/s]
Limit value is compared to the
current speed.
1
unsign
16
0 … 20,000 0 mm/s
Dyn. speed
hysteresis
in [mm/s]
Relative offset of the switching
point.
3
unsign
16
0 … 20,000 0 mm/s
Range
start dyn.
limit value
in [mm]
The dynamic speed limit value is
monitored starting from this
position.
5 sign32 -10,000,000 … 10,000,000 0 mm
8d
22
23f
23 m
Range end
dyn. limit
value in
[mm]
The dynamic speed limit value is
monitored up to this position.
9 sign32 -10,000,000 … 10,000,000 0 mm
Output data length: 13 byte
