9 Troubleshooting
The following information is used for rapid troubleshooting in the event of a malfunction.
9.1 What should I do if an error occurs?
If the AOPD shows an error on the display, the machine must be stopped immediately and
checked by an experienced technician. If it is found that the error cannot be clearly
defined and remedied, your local Leuze office and or the Leuze electronic hotline can
assist.
9.2 Diagnostics
Operational malfunctions often have simple causes that you can remedy yourself. The
following tables will help you do this.
9.2.1 Transmitter diagnostics
9.2.2 Receiver diagnostics
The receiver distinguishes between error codes (E xx) and fault codes (F xx). Only error
messages (E) provide information about events or states that you can eliminate. If the
receiver shows a fault code (F), it must be replaced. Consequently, only error codes (E)
are shown in the table below:
Symptom Measure to eliminate error
LED
is not lit
Check + 24 V DC supply voltage
Check connection cable
Replace transmitter if necessary
LED1 is lit red
continuously
Check the test input, hardware fault, replace transmitter if necessary
Table 9.2-1: Transmitter diagnostics
Code Cause / significance Measure to eliminate error
LEDs and 7-segment displays are not
lit
Check the + 24 V DC supply voltage
Check the connection cable, replace
the receiver if necessary
8 Lights continuously  Hardware error Replace receiver
F xx Internal hardware fault Replace receiver
E 00 Source of failure in the ambient area Eliminate the source of the failure
E 01 Short circuit between OSSD1 and
OSSD 2
Eliminate short circuit
Table 9.2-2: Receiver diagnostics
