11.4 Checklists
The inspection before the initial operation determines the safety related integration of the
active opto-electronic protective device (AOPD) into the machine and its control. The
results of the inspection must be written down and kept with the machine documents.
They can then be used as a reference during the subsequent regular inspections.
429075 CB-M12-15000S-5GF Connection cable shielded with M12 connection,
straight, length 15
m
429076 CB-M12-15000S-5WF Connection cable shielded with M12 connection,
angled, length 15
m
Connection cable, 8-wire for Receiver Extended
429081 CB-M12-5000S-8GF Connection cable shielded with M12 connection,
straight, length 5
m
429082 CB-M12-5000S-8WF Connection cable shielded with M12 connection,
angled, length 5
m
429083 CB-M12-10000S-8GF Connection cable shielded with M12 connection,
straight, length 10
m
429084 CB-M12-10000S-8WF Connection cable shielded with M12 connection,
angled, length 10
m
429085 CB-M12-15000S-8GF Connection cable shielded with M12 connection,
straight, length 15
m
429086 CB-M12-15000S-8WF Connection cable shielded with M12 connection,
angled, length 15
m
Power supply
520060 SITOP power Power supply 120/230 V AC ® 24 V DC / 5A, regula-
ted
520061 LOGO! power Power supply 120/230 V AC ® 24 V DC / 1,3A, regu-
lated
Test rods
349558 AC-TB 20 Test rod, 20 mm
349945 AC-TB 14/30 Test rod, 30 mm
349557 AC-TB 40 Test rod, 40 mm
Order
number
Item Description
Table 11.3-1: Accessories
