Lexmark CS410 series - Page 113

5 Remove the waste toner bottle.
1
2
6 Lift the blue levers on the imaging kit, and then pull the imaging kit until it stops.
1
1
2
2
7 Press down the blue lever, and then grasp the green handles on the sides to pull out the imaging kit.
1
2
Maintaining the printer 113
