2 Slide the release latch on the right side of the printer, and then open the top door.
1
2
3 Remove the toner cartridges by lifting the handles, and then gently pulling them away from the imaging kit.
1
2
4 Remove the right side cover.
1
2
Maintaining the printer 142
