Lexmark CS510 User Manual

2
3
6
4
5
1
Use the To
1 Rear USB port Attach a keyboard to the printer.
2 USB printer port Connect the printer to a computer.
3 Ethernet port Connect the printer to a network.
4 USB wireless port Attach an optional wireless network adapter.
5 Security lock port Lock the system controller board.
6 Printer power cord socket Connect the printer to a properly grounded electrical outlet.
Networking
Notes:
• Purchase a MarkNet
TM
N8352 wireless network adapter first before setting up the printer on a wireless network.
For information on installing the wireless network adapter, see the instruction sheet that came with the
adapter.
• A Service Set Identifier (SSID) is a name assigned to a wireless network. Wired Equivalent Privacy (WEP), Wi-Fi
Protected Access (WPA), WPA2, and 802.1X - RADIUS are types of security used on a network.
Preparing to set up the printer on an Ethernet network
To configure your printer to connect to an Ethernet network, organize the following information before you begin:
Note: If your network automatically assigns IP addresses to computers and printers, continue on to installing the
printer.
• A valid, unique IP address for the printer to use on the network
• The network gateway
Additional printer setup 41

Lexmark CS510 Specifications

General

Print Technology	Color Laser
Print Speed (Black)	32 ppm
Print Speed (Color)	32 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	up to 75, 000 pages
Standard Memory	512 MB
Maximum Memory	2560 MB
Processor Speed	800 MHz
Paper Input Capacity	250 sheets
Paper Input Capacity (Maximum)	1450 sheets
Paper Output Capacity	150 sheets
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB, Ethernet
Media Types Supported	Plain Paper, Card Stock, Labels, Envelopes
Media Sizes	A4, A5, A6, Executive, Legal, Letter
Mobile Printing	Lexmark Mobile Print
Toner Cartridges	Cyan, Magenta, Yellow, Black
