Lexmark CS510 User Manual

Using the printer control panel
1
From the home screen, navigate to:
> Settings > Print Settings > Setup Menu
2 From the Printer Usage list, select Max Speed or Max Yield.
3 Touch Submit.
Printing from a flash drive
Printing from a flash drive
Notes:
• Before printing an encrypted PDF file, you will be prompted to type the file password from the printer control
panel.
• You cannot print files for which you do not have printing permissions.
1 Insert a flash drive into the USB port.
Notes:
• A flash drive icon appears on the printer home screen when a flash drive is inserted.
• If you insert the flash drive when the printer requires attention, such as when a jam has occurred, then the
printer ignores the flash drive.
• If you insert the flash drive while the printer is processing other print jobs, then Busy appears. After these
print jobs are processed, you may need to view the held jobs list to print documents from the flash drive.
Warning—Potential Damage: Do not touch the printer or the flash drive in the area shown while actively
printing, reading, or writing from the memory device. Loss of data can occur.
Printing 70

Lexmark CS510 Specifications

General

Print Technology	Color Laser
Print Speed (Black)	32 ppm
Print Speed (Color)	32 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	up to 75, 000 pages
Standard Memory	512 MB
Maximum Memory	2560 MB
Processor Speed	800 MHz
Paper Input Capacity	250 sheets
Paper Input Capacity (Maximum)	1450 sheets
Paper Output Capacity	150 sheets
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB, Ethernet
Media Types Supported	Plain Paper, Card Stock, Labels, Envelopes
Media Sizes	A4, A5, A6, Executive, Legal, Letter
Mobile Printing	Lexmark Mobile Print
Toner Cartridges	Cyan, Magenta, Yellow, Black
