MPF gearbox removal

1 Remove the front door. See “MPF with front access cover removal” on page 201.

2 Remove the left cover. See “Left cover removal” on page 177.

3 Remove the main drive gearbox. See “Main drive gearbox removal” on page 178.

4 Disconnect the spring (A).

4600-830, -835, -895

Parts removal

179
