Lexmark MS321 Service Manual

Redrive gear plate removal
1 Remove the top cover. See “Top cover removal” on page 238.
2 Remove the left cover. See “Left cover removal” on page 177.
3 Remove the redrive assembly. See “Redrive assembly removal” on page 236.
4 Remove the two screws (A), and then detach the reverse solenoid.
Note: Do not disconnect the reverse solenoid cable from the controller board.
A
4600-830, -835, -895
Parts removal
237

Lexmark MS321 Specifications

General

Print Technology	Monochrome Laser
Memory	256 MB
Display	2-line LCD
Processor Speed	1 GHz
Maximum Monthly Duty Cycle	50, 000 pages
Recommended Monthly Page Volume	500 - 5000 pages
Input Capacity	250 sheets
Output Capacity	150 sheets
Connectivity	USB, Ethernet
Network Connectivity	Ethernet
Supported Operating Systems	Windows, Mac, Linux
Print Resolution	Up to 1200 x 1200 dpi
