Lexmark MS321 Service Manual

5 Using a #1 Phillips screwdriver, remove the screw (B).
B
6 Remove the sensor.
MPF pick roller and separator pad removal
1 Open the front door.
2 Press the latches (A), and then open the cover.
Warning—Potential Damage: Avoid damaging the MPF sensor
flag
(B) when removing the cover.
A
A B
3 Using a #1 Phillips screwdriver, remove the two screws (C).
4600-830, -835, -895
Parts removal
209

Lexmark MS321 Specifications

General

Print Technology	Monochrome Laser
Memory	256 MB
Display	2-line LCD
Processor Speed	1 GHz
Maximum Monthly Duty Cycle	50, 000 pages
Recommended Monthly Page Volume	500 - 5000 pages
Input Capacity	250 sheets
Output Capacity	150 sheets
Connectivity	USB, Ethernet
Network Connectivity	Ethernet
Supported Operating Systems	Windows, Mac, Linux
Print Resolution	Up to 1200 x 1200 dpi
