Lexmark MS321 Service Manual

Installation notes:
• To test if the spring and actuator are properly installed, press the actuator (A). The lock (B) should move up.
B
A
• Make sure that the tab (C) at the back of the cartridge guide is properly installed as shown.
Cartridge barrel shutter sensor kit removal
1 Remove the top cover. See “Top cover removal” on page 238.
2 Remove the right cover. See “Right cover removal” on page 186.
3 Disconnect the cable JCVR1 from the controller board.
4600-830, -835, -895
Parts removal
198

Lexmark MS321 Specifications

General

Print Technology	Monochrome Laser
Memory	256 MB
Display	2-line LCD
Processor Speed	1 GHz
Maximum Monthly Duty Cycle	50, 000 pages
Recommended Monthly Page Volume	500 - 5000 pages
Input Capacity	250 sheets
Output Capacity	150 sheets
Connectivity	USB, Ethernet
Network Connectivity	Ethernet
Supported Operating Systems	Windows, Mac, Linux
Print Resolution	Up to 1200 x 1200 dpi
