Develop

1 Developer roller

2 Toner cartridge

3 Photoconductor drum

The developer unit applies the toner from the toner cartridge to the photoconductor drum. The dierence in

charge causes the toner particles to attract to the photoconductor drum areas which are exposed to light.

4600-830, -835, -895

Theory of operation

293
