141Operations - TN3270E SETUP: SCS Options > PAPER SETTINGS > Tray 2 Orient (IDB Option 124)

Tray 2 Orient

(IDB Option 124)

This SCS Options > Paper Settings option selects the page orien-

tation for source input tray 2.

Advanced IDB language to set factory default:

&%IDB_EDIT: OPTION 124:2:EXIT

Option Value IDB Value

Portrait 0

Landscape 1

COR * 2
