284Appendix - TN3270e IDB Commands: How to Print an IDB Report

Appendix C -

Special TN3270e IDB Commands

How to Print an

IDB Report

1 From a Ready status in the operator panel press the MENU

button.

2 Use the navigation buttons: Option Card Menu > SCS/TNe

MENU > TN3270E SETUP > TEST OPTIONS > SCS IDB

Dump > Print.
