294Appendix - TN5250e IDB Commands: How to Print an IDB Report

Appendix E -

Special TN5250e IDB Commands

How to Print an

IDB Report

1 From a Ready status in the operator panel press the MENU

button.

2 Use the navigation buttons: Option Card Menu > SCS/TNe

MENU > TN5250E SETUP > TEST OPTIONS > Print IDB

Dump > Print.
