LEYBOLD TURBOLAB 80 User Manual

Description
13
300554859_002_C0 - 11/2016 - © Leybold
1.3 Technical Data
1.3.1 Backing pumps
DIVAC SCROLLVAC TRIVAC SOGEVAC
Backing pump 0.8 T 3.0 SC 5 D SC 15 D SC 30 D D 4 B D 8 B SV 16 D
Pumping speed m
3
/h 0.7 3.0 5.4 15.0 30.0 4.8 9.7 16
Noise level dB(A) 49 54 52 58 62 52 52 59
Exhaust connection G 1/8" thread
(silencer)
DN 16 KF DN 16 KF DN 25 KF DN 16 KF DN 16 KF G 1/2"
thread
1.3.2 Pump systems
TURBOLAB 80 TURBOLAB 90 TURBOLAB 250
Inlet flange DN 63 ISO-K 63 CF 63 ISO-K 63 CF 100 ISO-K 100 CF
Forevacuum
connection
DN 16 KF 16 KF 16 KF 16 KF 16 KF 16 KF
Pumping speed l·s
-1
65 65 90 90 225 225
Ultimate pressure mbar 8·10
-8
5·10
-10
8·10
-8
5·10
-10
8·10
-8
5·10
-10
Mains Supply
50/60Hz
V AC 110 ± 10 % / 230 ± 10 %
TURBOLAB 350 TURBOLAB 450
Inlet flange DN 100 ISO-K 100 CF 160 ISO-K 160 CF
Forevacuum
connection
DN 25 KF 25 KF 25 KF 25 KF
Pumping speed l·s
-1
290 290 430 430
Ultimate pressure mbar 8·10
-8
5·10
-10
8·10
-8
5·10
-10
Mains Supply
50/60Hz
V AC 110 ± 10 % / 230 ± 10 %
Rated power con-
sumption
110 V
230 V
VA
1760
3680
1760
3680
Product identification
To correctly identify the product when communicating with Leybold, always
have the information from the rating plate available. The nameplate is located
next to the power supply connection MAINS X20.
