EXTERNAL EQUIPMENT SETUP
29
OTHER A/V SOURCE SETUP
Camcorder
Video Game Set
Connect the
AUDIO
/
VIDEO
jacks between TV and
external equipment. Match the jack colors
.
(
Video = yellow, Audio Left = white, and Audio Right = red
)
1. How to connect
2. How to use
■
Select
AV1
input source with using the
INPUT
button on
the remote control.
■
If connected to
AV IN 2
input, select
AV2
input source.
■
Operate the corresponding external equipment.
1
AV IN 2
L/L/MONOMONO
R
AUDIOAUDIO
VIDEOVIDEO
S-VIDEO
L R
VIDEO
i.e) 42/50PB4D
