6-8
FAILURE MODE FLOW CHART
Cook-top does not heat
Remove the main PCB(002A) harness
and pull the main PCB(002A) forward from the PCB case
Inspect the main PCB(002A)
Wide pattern(Live part) blown out
Normal?
END
No
NoYes
Repair and fix
END
Replace
the main PCB(002A)
Repairable
by yourself?
Yes
